Modern Grey Series
features a sophisticated slate palette for a serene, contemporary atmosphere. Utilizing advanced Synchronized Press Edge technology, the surface achieves a profound 3D depth mirroring authentic timber. This integrated pressing process ensures seamless transitions between planks, enhancing the floor's premium architectural silhouette.Engineered for durability, each plank features a 0.5mm wear layer SPC flooring for superior resistance against scratches and heavy traffic. For ultimate comfort, the structure includes a high-density ixpe underlayment SPC flooring system.
Premium SPC Rigid Core Flooring
- Certified 100% Waterproof
- Innovative Lightweight Core
- Superior Wear Layer Protection
- Ergonomic Impact Absorption
- Slip-Resistant Surface (R10)
- Composition: Rigid Stone Plastic
- Process: Advanced Foamed Core
- Bevel: Integrated Pressed Edge
- Fire Rating: Bfl-s1 Standard
- Compliance: FloorScore, CE, SGS
The Core Secret: Why Our 3:1 Ratio Matters
Limestone (Calcium Carbonate) vs. PVC Resin Ratio Analysis
Optimized Polymer Bond
- Higher Resin Content: Better elasticity and impact resistance.
- Unbreakable Click Lock: Enhanced polymer tenacity prevents joint snapping.
- Flexibility: Can withstand minor subfloor unevenness without cracking.
- Longevity: Maintains core integrity for 25+ years in commercial settings.
Limestone Overloaded
- High Brittleness: Excess calcium powder makes the plank "stone-brittle".
- Fragile Click-Lock: Joints are prone to snapping during installation or expansion.
- Low Cost, High Risk: Reduces production cost by adding cheap filler.
- Poor Stability: Higher risk of buckling under thermal fluctuations.
Technical Conclusion
By utilizing a 3:1 ratio, Ventoce increases production costs by ~12% compared to market standards. However, this investment ensures superior Shore D hardness and impact strength, effectively eliminating the #1 complaint in SPC flooring: Click-lock fracture.
Techinical Specification
| Total Thickness | 4.5mm / 5.0mm / 6.5mm (Customizable) |
|---|---|
| Wear Layer | 0.3mm (Residential) / 0.5mm (Commercial) |
| EVA Thickness | 1.5mm |
| Plank Size | 1220 x 180 mm / 1500 x 228 mm |
| Core Material | Lightweight Micro-foamed SPC (20-25% Lighter) |
| Fire Resistance | EN 13501-1 Class Bfl-s1 |
| Formaldehyde | E1 Grade / FloorScore Certified |
| Slip Resistance | DIN 51130 R10 |
| Click System | Unilin |
| SPC Skirting Board | 2400 * 80 * 15 mm (0.49 Kgs/pc) |
|---|---|
| SPC T-Molding | 2400 * 40 * 11 mm (0.50 Kgs/pc) |
| SPC End-cap | 2400 * 35 * 9 mm (0.72 Kgs/pc) |
| Stairnose Overlap | 2400 * 55 * 18 mm (1.35 Kgs/pc) |
| Flush Stairnose | 2400 * 78 * 25 mm (2.20 Kgs/pc) |
| Packing Info | Standard Export Cartons (2420mm length) |
